DESCRIPTION
This Uniview IP Camera Kit comes equipped with four high definition 4MP progressive scan turret cameras and a four-channel plug-and-play NVR with 4 PoE network interfaces and everything you need to install it yourself. Just plug the cameras in to the NVR and they will auto-configure.
The cameras are equipped with day/night functionality and feature an IR distance of up to 30 meters for visibility in low lighting. Each camera is IP67-rated for outdoor use and Ik10-rated for anti-vandalism.
The 4-channel NVR supports third-party cameras with ONVIF conformance: Profile S, Profile G, Profile T and RTSP protocols. Smart VCA (Video Content Analysis) features include Face Detection, Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, and Audio Detection. The 4-channel 8MP plug & play NVR offers easy free remote access with free iOS, Android, Windows and Mac apps.
NOTE: Plug and play camera set up - just plug them in (network cables not included)
- The 2.8mm lens provides a wider field of view with a slightly lower pixel density.
- One 8-channel PoE NVR with decoding up to 6-ch@1080p
- Four 4MP fixed turret ColorVu cameras with 2.8 mm fixed focal lens - horizontal FOV: 113° vertical FOV: 62° diagonal FOV: 137°
- 24/7 colorful imaging with F1.0 aperture and 0.001 Lux illumination
- 2 TB pre-installed HDD
- Water and dust resistant (IP67)
- IP67 rated with -30 °C to 60 °C (-22 °F to 140 °F) operating and storage conditions
Camera Specifications
- Day/night functionality
- Smart IR, up to 30 m (98 ft) IR distance
- 2D/3D DNR (Digital Noise Reduction)
- Ultra 265, H.265, H.264, MJPEG
- ROI (Region of Interest)
- ONVIF Conformance
- IK10 vandal resistant
- IP67-rated
- Camera sensor: 1/3", 4.0 megapixel, progressive scan, CMOS
- Minimum Illumination: Colour - 0.01 Lux (F2.0 AGC ON), 0 Lux with IR on
- Adjustment Angle: Pan - 0° to 360°, Tilt - 0° to 75°, Rotate - 0° to 360°
- Lens Type: 2.8mm and 4.0mm @2.0, Fixed-focal
- Camera Power: DC 12V±25%, PoE (IEEE 802.3af)
- Camera Operating Temperature: -30°C to +60°C (-22°F to +140°F)
NVR Specifications
- Support Ultra 265/H.265/H.264 video formats
- 4-channel input
- Plug & Play with 4 independent PoE network interfaces
- Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T
- Support 1-ch HDMI, 1-ch VGA
- HDMI and VGA simultaneous output
- Up to 8MP resolution recording
- 1 SATA HDD
- Support cloud upgrade
- NVR Incoming/Outgoing Bandwidth: 64Mbps/48Mbps
- NVR Recording Resolution: 4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
- NVR Network Interface: 1 x RJ45 10M/100M self-adaptive Ethernet Interface
General
- Power Supply: 48V DC
- Power Consumption: ≤9 W (without HDD)
- Working Environment: -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)
- Dimensions(W×D×H): 260mm ×240mm × 46 mm (10.2" × 9.4" ×1.8")
- Weight ( without HDD ): ≤1.1kg (2.43lb)
- Max 54W in total
