General Specifications
Noise Figure Options 0.7 dB
L.O. stability (over temperature) ± 25 kHz
L.O. phase noise -75 dBc/Hz Max @ 1 kHz
Conversion gain 60 dB typical (±0.5dB/25 MHz Segment)
Output level (1dB compression) +7 dBm min
Power requirements +15 to +24 VDC, 150 mA typical
Input VSWR 2.2:1
Dimensions 3.9" x 1.7" x 1.7"
(100 x 42 x 42 mm)
Weight 10.6 oz. max (300 g)
Output connector Standard 75 ohm F connector
Input Interface WR-75 Waterproof (Mated with matching flange and O-ring)
Image Rejection 45 dB minimum, 60 dB typical
Gain Stabilty 6 dB p-p maximum, 3 dB typical over temperature and frequency
Gain Stabilty 1.5 dB p-p maximum per 27 MHz segment
1 dB Gain Compression Point + 7 dBm
Local Oscillator Leakage -45 dBm maximum measured at waveguide input
Size 100(L) x 42(W) x 42(H) mm
3.9 x 1.7 x 1.7 in.
Weight 300g / 10.6 oz maximum
Paint / Color White, Plastic Shell

Environmental Specifications
Operating Temperature -40 to +60 degrees Celsius
Thermal Gradient -40 degrees Celsius/Hour
Relative Humidity 15% to 100% condensation and frost

Power Requirements
Input DC Voltage +15 to 24 V supplied through center conductor of IF cable
Current Drain 200 mA maximum, 150 mA typical
