Specifications:
* Input freq. range: 3.2 to 4.2GHz
* L.o. frequency: 5150MHz (+/- 500KHz @ 25 degree Celsius)
* L.o. stability: +/-1.5MHz (-40 to +70 degree Celsius)
* Output freq. range: 950 to 1750MHz
* Noise figure: 13 degree K typ.
* Conversion gain: 55dB typ.
* Input VSWR: 2.5:1 (max.)
* Output VSWR: 2.0:1 (max.)
* Output connector: F-female connector
* Output impedance: 75 ohms typ.
* Cross polar isolation: 20dB (min.)
* Image rejection: 45dB (min.)
* Phase noise: -85dBc @ 10KHz (min.)
* Supply voltage:
11.5 to 14.0V (vertical polarization)
16.0 to 19.0V (horizontal polarization)
* Operating temperature: -40 to +70 degree Celsius
* Storage temperature: -40 to +80 degree Celsius
* Relative humidity: 0% to 95%
* Weight: 427g
